Silo Structure
Our team provided the complete structural design, including FEA (SCIA Engineer), connection detailing (IDEA StatiCa), and drawings for the silo structure.
Our team provided the complete structural design, including FEA (SCIA Engineer), connection detailing (IDEA StatiCa), and drawings for the silo structure.
Our engineering team has completed more than 500+ steel connections for the last 3+ years using IDEA StatiCa Steel. Projects have been executed in different regions of Europe and designed using the Eurocode standards.
The project involved the renovation and extension of an existing building through the construction of a new structural section. To meet modern engineering requirements, the existing structure was reinforced, and parts of it were dismantled. New load-bearing elements were introduced to ensure the stability and durability of the extended building. Our team developed a detailed …
Reconstruction and extension of an existing building, Germany Read More »
Our team carried out detailed 3D modeling for part of a hydraulic project. A key challenge was the client’s requirement for completely clash-free reinforcement within the 3D environment. Due to the variable geometry of the slabs and walls, extremely precise placement of the reinforcement was required, tailored to the specific conditions of each area.
The project features an industrial hall with a combined steel and reinforced concrete structure. Our team modeled the concrete part in 3D, including detailed formwork and reinforcement plans in both 3D and 2D, ensuring precise execution and coordination on site.
Total volume 11 689 l; Outside diameter O.D.=2 050 mm, L=3 840mm; Empty weight 3 161kg; Weight operating max 15 166kg; Weight at test 15 185kg.
Total volume 52 710 l; Outside diameter O.D.=2 900 mm, L=8 681mm; Empty weight 7 088 kg; Weight operating max 59 717 kg; Weight at test 59 878 kg.
Newconstruction of 4 residential buildings with18 residential units andunderground parking. Thestructure consists of 4 parts of the building (A, B, C and D) which areinterconnected by underground parking.
The bar is made of a light metal support structure. Bolted connections are used to facilitate assembly and disassembly when necessary.The foundation is made of single footings resting on a well compacted gravel cushion 0,30 m thick. The supporting structure on the short side is framed and made of IPE 160. In the other direction, …
The project compriseseight sub-objects developed on the basis of an architectural and technologicaldesign. The Truck Unloading area has a mixed constructiontype. Up to an elevation of ±0.00 m, itis solved with a monolithic reinforced concrete structure, and then it iscovered with a steel canopy. The steel bunker has plan dimensions of 4.0/8.0 m …
A Silo Holding for storing rice arpa and rice seeds, Bulgaria Read More »
